Shell and Tube Lubricating Oil Cooler

Features/Functions:

1. The cooling water passes through the pipe, and the lubricating oil flows between the shells and the pipes. The direction of cooling water is opposite to the oil flow, so the cooling effect is better.

2. Shell and Tube Lubricating Oil Cooler is used to cool the hot lubricating oil, and keep the temperature of oil not too high.
