Gear pump

Features/Functions:

1. There is a pressure relief groove milled on the end wall of the shell, and the squeezed fuel can be guided into the oil chamber along this groove. The trapped oil can be released.

2. When the gear rotates, the fuel fills the inlet chamber and the cavity between the two teeth, and is carried to the discharge chamber with increasing pressure.
